- Double-sided design accommodates two bushings that easily change out with a hex wrench
- Efficiently & precisely strip 600V secondary cable without damaging the conductor, even in cold climates
- Compatible square cut bushings for stripping 60 mil to 110 mil secondary insulations with concentric, compressed or compacted conductors #1/0 AWG to 1,000 kcmil
- Guarded bushing cutting blades prevent injury
- TOOL BODY ONLY, BUSHINGS SOLD SEPARATELY. If you would like to order bushings, please see the note below. You can also order the bushings separately using the links under the Bushing Sizes heading below.
NOTE: The WS 22 is available with or without bushings. If you would like to order the WS 22Â with 2 bushings, please take a look at the available square or chamfer cut bushings from the bushings below and submit a Request for Quote. A Powertech Associates representative will get back to you within 24 hours.
Â
Compatibility:
Conductor Type: | Concentric, Compressed, Compacted |
Cable Compatibility: | Secondary Distribution |
Cable Access: | End |
Min. Cable Outer Diameter: | #1/0 AWG |
Max. Cable Outer Diameter: | 1000 kcmil |
Max. Voltage: | 600 V |
Insulation Thickness: | 60-110 mils |
Specifications:
Max. Bushing Capacity: | 2 |
Comparison Chart:
Model | Part # | Item Description | Length | Weight |
|---|---|---|---|---|
WS 22 | 12304H | Tool Body Only (Bushings Sold Separately) | 6″ | 1 lb |
